Rated Voltage | AC 12V,24V,48V,100V,120V,230V | Dieelectric Stength | 1500VAC/1min |
Power Consumption | ≤4 Watts | Noise | <40dB |
Input Current | <25mA | Coil Temperature Rise | ≤60K |
Rated Frequency | 50/60Hz | Insulation Class | E |
Speed | 0.1,1,2,3,4,5,10,15,60 rpm | Insulated Electricity Power | 1500 VAC / 1Min |
Running Torque | 1.5 kg-cm ~ 20kg-cm | Direction of Rotation | CW,CCW or Free |
Insulation Resistance | >100MΩ |
|
|
